Banner TL50 Pro Select Series merupakan programmable RGB tower light yang dirancang untuk memberikan indikasi status mesin secara lebih fleksibel dibanding tower light konvensional. Setiap segmen lampu dapat dikustomisasi dengan berbagai pilihan warna, pola berkedip (flash), tingkat kecerahan (dimming), hingga animasi dinamis menggunakan Banner Pro Editor Software atau melalui komunikasi IO-Link pada model yang mendukung.

‍

Dengan desain yang kokoh, ringkas, dan telah dirakit sepenuhnya (no assembly required), TL50 Pro Select mempercepat proses instalasi sekaligus mengurangi kompleksitas inventori karena satu perangkat dapat diprogram ulang sesuai kebutuhan aplikasi. Tersedia pilihan model 3-segment maupun 4-segment, serta opsi audible alarm omnidirectional untuk memberikan notifikasi visual dan suara secara bersamaan.

‍

Applications

‍

TL50 Pro Select cocok digunakan pada berbagai aplikasi industri, seperti:

Indikator status mesin produksi
Assembly line dan workstation
Mesin packaging
Conveyor system
Material handling
Automated manufacturing
AGV/AMR station
Mesin CNC dan machining center
Quality inspection station
Andon system dan visual factory

‍

Tower Lights
Series Name	Segment Diameter (mm)	Mounting Hole Diameter (mm)	AC/DC	IP Rating	RGB Programmable	Audible	Daylight Visible	Wireless	Modular Construction
TL50 Pro	50	30	DC	IP50, IP67	Pro, IO-Link	✅ YES	✅ YES	🚫 NO	🚫 NO
TL50 Pro Select	50	30	DC	IP65	Pro, IO-Link	✅ YES	✅ YES	🚫 NO	🚫 NO
TL50 Core	50	30	AC or DC	IP50, IP67	🚫 NO	✅ YES	✅ YES	🚫 NO	🚫 NO
TL50 Andon	50	—	DC	IP54	🚫 NO	✅ YES	🚫 NO	✅ YES	🚫 NO
TL70 Pro	70	30	DC	IP65	Pro, IO-Link	✅ YES	🚫 NO	🚫 NO	✅ YES
TL70 Basic	70	30	DC	IP65	🚫 NO	✅ YES	🚫 NO	🚫 NO	✅ YES
TL70 Core	70	30	AC or DC	IP65	🚫 NO	✅ YES	🚫 NO	✅ YES	✅ YES
TL30	30	30	DC	IP65	🚫 NO	✅ YES	🚫 NO	🚫 NO	🚫 NO
CL50 Pro	50	30	DC	IP65	Pro, IO-Link	✅ YES	🚫 NO	🚫 NO	🚫 NO
CL50 Core	50	30	DC	IP65	🚫 NO	✅ YES	🚫 NO	🚫 NO	🚫 NO
TLF100 Pro	100	—	DC	IP65, IP69K	Pro, IO-Link	✅ YES	✅ YES	🚫 NO	🚫 NO
WLS27 Pro	27	—	DC	IP66, IP67, IP69K	Pro, IO-Link	🚫 NO	✅ YES	🚫 NO	🚫 NO
WLS27 Core	27	—	DC	IP66, IP67, IP69K	🚫 NO	🚫 NO	🚫 NO	🚫 NO	🚫 NO
TL15	15	—	DC	IP66, IP67, IP68	🚫 NO	✅ YES	🚫 NO	🚫 NO	✅ YES

Technical Specifications
Power
Supply Voltage	12 ~ 30 VDC (Class 2 / SELV Power Supply)
Supply Protection	Reverse polarity & transient voltage protection
Maximum Current per LED Segment	12 VDC: 92 mA 24 VDC: 50 mA 30 VDC: 44 mA
Maximum Audible Current	Omni-Directional Sealed Audible: 45 mA
Electrical
Input Rating	Leakage Current Immunity: 400 µA Indicator Response Time: 250 ms (Max.)
PWM Input	Duty Cycle: 0–100%
PFM Input	Frequency: 100–10,000 Hz
Required Overcurrent Protection	20 AWG: 5.0 A 22 AWG: 3.0 A 24 AWG: 2.0 A 26 AWG: 1.0 A 28 AWG: 0.8 A 30 AWG: 0.5 A
Connection & Construction
Connection	5-pin atau 8-pin M12 Male Quick Disconnect Connector atau Kabel PVC 1,2 m (4 ft), tergantung model
Construction	Base, Cover, dan Light Segment berbahan Polycarbonate
Environmental
Protection Rating	IP65, UL Type 4X
Operating Temperature	Non-Audible: -40°C hingga +50°C Audible: -20°C hingga +50°C
Humidity	95% RH maksimum pada +50°C (non-condensing)
Mechanical
Vibration Resistance	10–55 Hz, 1.0 mm Peak-to-Peak (IEC 60068-2-6)
Shock Resistance	30 G, 11 ms Half Sine Wave (IEC 60068-2-27)
Audible Alarm
Oscillation Frequency	3.1 kHz ± 500 Hz
Sound Intensity	93 dB pada jarak 1 meter (Typical)
Certifications
Certification	Banner Engineering BV (CE Compliance)

* Specifications are subject to change without prior notice. Please refer to the official Banner Engineering datasheet for the latest technical information.
